Fire-protected wood
In order for it to be possible to build with wood, as a surface layer or cladding, where there are higher requirements than the wood's natural properties, you need to install a wood product that meets the requirements specified according to fire protection documentation.
Here you will find quick and clear facts about what Woodsafe Timber Protection AB can help you with.
If you cannot find what you are looking for, contact customer service:
+46 (0) 10 206 72 30
kundtjanst@woodsafe.com
Euro class B-s1,d0
Let us explain
Wooden surface layers in, for example, public spaces often set a higher fire class requirement than the wood itself. But there are more important features to consider.
Euro class B-s1,d0
Let us guide you
Building with wood often requires a better fire class than the wood's own, e.g. euro class B-s1,d0 in public spaces such as hotels, hospitals, schools, sports halls and similar. The fire class is often combined with K210, which in BBR is referred to as K210/B-s1,d0, which means that the material itself must meet the fire property.
Some of the measuring points that are measured are:
- Development of heat energy (THR)
- Smoke development (TSP)
- Burning Intensity Growth Rate (Figure)
- Burning Particles
Property which is classified based on the structure and constituent materials where the prerequisites are described in Field of application. We want to make you aware of this information, for example:
- Is the product approved with an air gap?
- Is the product approved with a painted surface?
- Is the product approved with insulation?
- Is the product approved as a sparse panel?
Fire classes
Our offer
Woodsafe Timber Protection AB is a service link to carefully selected partners in the wood industry. Due to the width of our collaboration, there are several different choices of wood, assembly and surface treatment that meet the fire class.
This is our fire class offer
Examples of options to choose from
Woodsafe is a service link to carefully selected partners. Due to the breadth of our collaboration, there are several different options to use wooden panels that meet fire class B and C, for example B-s1,d0. In the list, we show an overview of wood types that are all approved with or without air gaps. For more information contact customer service +46 10 2067230 or kundtjanst@woodsafe.com, alternatively contact our partners directly
WOODSAFE® PRO™
Note: several surface treatments are available.
- Spruce, Pine, Maple, Birch, Oak, Ash, >12mm thickness
- Heat-modified Pine, >12mm thickness
Poplar, >15mm thickness - Cedar, > 19mm thickness
- Siberian larch, >21mm thickness
WOODSAFE® Exterior WFX™
Note: several surface treatments are available.
- Cedar, >9mm thickness
- Accoya, >17mm thickness
- Spruce, Pine, Siberian Larch, >18mm thickness klek
- Douglas Fir, Oregon Pine, >18mm thickness
- Oak, >19mm thickness
- Heat-modified Spruce, >18mm thickness
- Nobelwood, Ayous, >18mm thickness
- Heat-modified Poplar, Frake, >18mm thickness
- Heat-modified Pine, >21mm thickness
SP FIRE 105
Let us explain
Wood cladding in Br1 buildings requires the wood cladding to meet the requirements of SP FIRE 105. But there are more important properties to consider.
SP FIRE 105
Let us guide you
Building a wooden facade cladding requires that the cladding meets SP FIRE 105 as an alternative to non-combustible material in building class Br1. According to the testing method, it is the construction that must meet the majority of requirements and where the design and materials used affect the final result.
Some of the measurement points that are measured are:
- Falling parts
- Radiant heat
- Eaves temperature
- Fire spread along the facade
- Fire spread in the structure
Overall, SP FIRE 105 encloses many factors that affect the entirety, and you as a regulatory party or downstream user must be aware of how your facade cladding is structured and also in relation to the type of wood in question.
We also want to draw your attention to the fact that SP FIRE 105 does not say anything about the fire protection's suitability for use in exterior applications. But so does the service class assessment that goes under the standard EN16755 EXT.
SP FIRE 105
Our offer
Woodsafe Timber Protection AB is a service link to carefully selected partners in the wood industry. Due to the width of our collaboration, there are several different options for using wood cladding systems that comply with SP FIRE 105.
This is our SP FIRE 105 offer
These are the options to choose from
Woodsafe is a service link to carefully selected partners in the wood industry. Due to the breadth of our collaboration, there are several different options for using wood cladding systems that meet SP FIRE 105. In the list, we show an overview of approved systems. For more information contact customer service +46 10 2067231 or kundtjanst@woodsafe.com alternatively contact our partners directly
Woodsafe PRO™
Facade system for traditional cover painting
- Spruce, >21mm thickness
- Materials included
- Wooden nail plate
- Cover painted
Woodsafe Exterior WFX™
Facade system for natural aging
- Woodsafe Exterior WFX™
- Thermowood pine
- Heat modified spruce
- Cedar panel
- Cedar chips
- 3-ply spruce
- Included materials
- Wood nail bed
- Concealed fastening
- Stone wool
- Glasullo Phenolic insulation
- XPS insulation
- CLT substrate (D-class)
- Aeration batten
- Colored
Service class
Let us explain
Fire rating is one thing, but what does the fire rating tell us about the product's suitability for different environments? We explain the importance of ensuring the service class.
EN16755 (service class)
Let us guide you
Fire protection systems can meet fire engineering requirements. But the system's properties may be unsuitable for use in exterior environments or in interior environments with high humidity.
Usage classes are divided according to:
- INT1, indoors
- INT2, indoors with higher humidity
- EXT, outdoor use
- Burning particles
For exterior use, it is particularly important to ensure basic prerequisites:
- Is the product approved with requirements for covering facade paint?
- Is the product approved without requirements for covering facade paint?
BS-EN16755 EXT is not equivalent to EN16755 EXT
Great Britain has, for reasons of unusualness in the standards cooperation in Europe, chosen to depart from basic requirement specification according to EN16755 EXT. In practice, the BS standard means that the requirements for the difference between incoming and outgoing fire technical parameters are not assessed. The BS-EN16755 standard has not been adopted by CEN and is not applicable in other member countries.
Service class
Our offer
Woodsafe Timber Protection AB, as the only manufacturer of fire-impregnated wood, offers you to choose between two fire impregnation systems. Both systems are covered by type-approved properties according to EN16755 INT1, INT2 and EXT.
This is our service class offer
Examples of options to choose from
Woodsafe is a service link to carefully selected partners. For more information contact customer service +46 10 2067230 or kundtjanst@woodsafe.com, alternatively contact our partners directly
WOODSAFE® PRO™
Fire impregnation system with type-approved EN16755 in its entirety. In an exterior environment such as facade cladding, the wooden panel must be surface treated with a film-forming paint system according to instructions.
WOODSAFE® Exterior WFX™
Fire impregnation system with type-approved EN16755 in its entirety without requirements for surface treatment in exterior application.
Example of product selection:
- Normal indoor environment
- WOODSAFE® PRO™
- Attic spaces
- WOODSAFE® PRO™ alternatively Exterior WFX™
- Spa & bathhouse facilities and the like
- WOODSAFE® PRO™, surface treated alternatively Exterior WFX™
- Facade cladding painted
- WOODSAFE® PRO™
- Facade cladding neutral, or lasered
- WOODSAFE® Exterior WFX™
